Home > Sell > 160KW Diesel Generator Set 200KVA 230V AC Three Phase Diesel Generators
160KW Diesel Generator Set 200KVA 230V AC Three Phase Diesel Generators
Hits: 573
Price: 15.00Dolla/Piece
Min quantity: 1 Piece
Quantity: 999 Piece
Deliver: In 7 days
Expiry: Long-term
Update date 2023-03-03 10:25

Detail

Overview

Essential details

  • Warranty:

  • 13 months

  • Certification:

  • CE

  • Place of Origin:

  • Jiangsu, China

  • Brand Name:

  • TONTEKPOWER

  • Model Number:

  • TPD200C6-1

  • Rated Voltage:

  • 440V (Can be adjusted)

  • Speed:

  • 1800RPM

  • Frequency:

  • 60HZ

  • Rated Power:

  • 160KW/200KVA

  • Standby Power:

  • 176KW/220KVA

  • Engine brand:

  • CUMMINS

  • Engine model:

  • 6CTA8.3-G1

  • Engine type:

  • In line,6 cylinders,4 stroke

  • Cooling method:

  • Water cooled by radiator

  • Alternator brand:

  • STAMFORD/MARATHON

  • Power factor:

  • 0.8 (lagging)

  • Phase and wire:

  • 3 phase 4 wires

  • Protection class:

  • IP23

Supply Ability

  • Supply Ability

  • 150 Piece/Pieces per Month

Packaging & delivery

  • Packaging Details

    • PE FILM PACKING
    PACKING: STANDARD SEAWORTHY PACKING

  • Port

    • SHANGHAI

  • Lead time:

  • Quantity(units)1 - 1>1
    Lead time (days)15To be negotiated

DIESEL GENERATOR DATA

Generator set model

TPD200C6-1

Generator rated power

160KW/200KVA

Rated frequency

60HZ

Rated voltage

440V (Can be adjusted)

Rated speed

1800RPM

Fuel consumption

42L/h

Open type size

2255x840x1560 MM

Open type weight

1600 Kg

ENGINE DATA

Engine model

6CTA8.3-G1

Engine brand

CUMMINS

Bore & Stroke

114 × 135 mm

Displacement

8.3 L

Compression ratio

 17.3:1

Fuel consumption at 100% load

245 g/kW.h

Type

In line,6 cylinders,4 stroke

Aspiration

Turbocharged & Aftercooled

Governor

Electronic

Cooling method

Water cooled by radiator

ALTERNATOR DATA

Alternator brand

STAMFORD/MARATHON

Power factor

 0.8 (lagging)

Phase and wire

3 phase 4 wires

Excite type

Single Bearing, Close coupled. Brushless, self-exciting,AVR

Protection class

IP23

Insulation class

H
