Home > Sell > 180mm electric 380V 2.3KW 1500RPM servomotor AC servo motor drive for sewing machine
180mm electric 380V 2.3KW 1500RPM servomotor AC servo motor drive for sewing machine
Hits: 379
Price: 600.00Dolla/Piece
Min quantity: 1 Piece
Quantity: 999 Piece
Deliver: In 7 days
Expiry: Long-term
Update date 2023-02-15 15:19

Detail

Overview

Essential details

  • Warranty:

  • 3months-1year

  • Place of Origin:

  • Zhejiang, China

  • Brand Name:

  • XINYUHAI

  • Model Number:

  • 180SY-M15015S1H-3

  • Type:

  • SERVO MOTOR

  • Frequency:

  • 50/60Hz

  • Phase:

  • Three-phase

  • Protect Feature:

  • IP65

  • AC Voltage:

  • 380V

  • Efficiency:

  • IE 4

  • Number of pole pairs:

  • 5

  • Encoder Brand:

  • Tamagawa(From Japan)

  • Output Power:

  • 2.3KW

  • install:

  • Flange mountiong

  • Insuation resistance:

  • DC500v ,10M above

  • environment temperature:

  • 0 °C - 55 °C

  • Vibration:under:

  • 2.5G

  • Insuation and voltage resistance:

  • AC1500V,1minute

  • Voltage:

  • 380v

  • Certification:

  • CE, ISO

Supply Ability

  • Supply Ability

  • 10000 Piece/Pieces per Month

Packaging & delivery

  • Packaging Details

    • Cartons or wooden box

  • Port

    • NINGBO or SHANGHAI

  • Picture Example:

  • package-img

  • Lead time:

  • Quantity(pieces)1 - 10>10
    Lead time (days)5To be negotiated

180mm electric 380V 2.3KW 1500RPM

servomotor AC servo motor drive for sewing machine

Motor Model

 180SY-

M15015

  S1H-3

180SY-M18015 S1H-3

180SY-

M28015S1H-3

180SY-

M35015

S1H-3

180SY-

M18015

S1H

180SY-

M28015

S1H

180SY-

M35015

S1H

180SY-

M48015

    S1H

Rated Power(Kw)

2.3

2.8

4.4

5.5

2.8

4.4

5.5

7.5

Rated Torque(N.m)

15

18

28

35

18

28

35

48

Max Torque(N.m)

45

54

84

105

39.6

47.6

59.5

81.6

Rated  Speed(Rpm)

1500

1500

1500

1500

1500

1500

1500

1500

Max Speed(Rpm)

3500

3500

3500

3500

2500

2100

2100

   2100

Rated Current(A)

9.7

10.8

16

21

8.6

11.2

13

18

Rotor Inertia(Kg.㎡)

2.9*10-3

4.6*10-3

6.8*10-3

8.9*10-3

 4.6*10-3

 6.8*10-3

8.9*10-3

12.5*10-3

Motor Weight(Kg)

12.9

14.5

19.1

24

14.5

   19.1

24

30.5

1. High level of integration

2. Fast response
3. Protect perfectly
4. High reliability
Yaskawa Sigma-7 type driver


Pls contact me for more details about the servo driver !
we have tamagawa incremental 2500PPR /5000PPR and absolute 17BITS /23BITS !
STANDARD MODEL:SUPPORT PULSE AND DIRECTION, MODBUS RS485, INTERNAL POSITION CONTROL, AUTOMATIC TUNING
