Overview
Essential details
Warranty:
3months-1year
Place of Origin:
Zhejiang, China
Brand Name:
JULANTE
Model Number:
Y Y2 Y3
Type:
ac electric motor
Frequency:
50HZ/60HZ
Phase:
Three-phase
Protect Feature:
Totally Enclosed
AC Voltage:
380v±5% and customize
Efficiency:
IE 1
Cooling type:
IC0141
Protection class:
IP54/IP55
Duty:
S1
Brand:
Julante and OEM
Altitude:
not exceeding 1000m
Apply machines and equipments:
drilling machines ,blowers , pumps and so on
Insulation class:
B/F
Color:
blue /yellow/red/customize
Ambitent temperature:
-15℃≤0≤40℃
Certification:
CCC, ce, ISO9001-2008
Supply Ability
Supply Ability
10000 Piece/Pieces per Month electric motor 35kw
Packaging & delivery
Packaging Details
electric motor 35kw
Bubbles, carton and plywood
Port
ningbo shanghai guangzhou yiwu
Lead time:
Quantity(pieces) 1 - 30 >30 Lead time (days) 15 To be negotiated
Product Description
Y series motors are totally enclosed and fan cooled(TFEC).Three-phase squirrel cage induction motors. They are newly designed in conformity with the relevant requirements oi IEC standards. Y series motors have outstanding performance, such as high efficiency, energy-saving, high starting torque, low noise, little vibration, reliable operation and easy maintenance, etc.
Y series motors are widely used in many places, where do exist combustible, explosive or corrosive, and with any special
requirements, such as drilling machines, pumps, fans, mixer, transport machines, food machines agriculture machines and equipments etc.
Y2 Series motors are totally enclosed fan cooled(TEFC). squirrel cage three-phase induction motors,developed with new technique They are renewal and upgrading products of Y series The mounting dimension is fully conformed with IEC standard .
The motors have the merits of beautiful modeling .compact structure ,low noise,high efficiency,large staring torque, easy serving, etc The motors are adopted with F class insulation and designed with assessing method for insulation
practice. It enhances greatly motor's safety and reliability.These motors have reached an international advanced level Y2 series motors can be widely used in various machines and equipments. such as drilling machines,blowers
,pumps,compressors,transporters,agricultural and food processing machines.
Y3 series three-phase asynchronous motors, developed with new techniques. Aluminium body.
Y3 series motors are defined as totally enclosed, fan cooled, squirrel cage type and noted for their novel design, beautiful
model, compact structure, low noise, high efficiency, large torque, excellent starting performance, easy serving, etc. The motors
are adopted with F class insulation and designed with assessing method for insulation system according to international practice,
it have greatly reached an international advanced level of the same kind of products at the initial days of 90s.
Y3 series motors can be widely used as driving equipments of various machineries, such as machine tools, blowers, pumps,
compressors, transporters, agricultural and food processing. Pedestal installation size and centre height and other indexes of the
motor completely measured by Y3 series three-phase asynchronous motor.
Product parameters
Company profile
