Overview
Essential details
Warranty:
3months-1year
Place of Origin:
Zhejiang, China
Brand Name:
JULANTE
Model Number:
MS series electric motor
Type:
Induction Motor
Frequency:
50HZ
Phase:
Three-phase
Protect Feature:
Totally Enclosed
AC Voltage:
380V or customized
Efficiency:
IE 1
color:
yellow / red /blue/customized
ambient temperature:
-15℃≤0≤40℃
altitude:
not exceeding 1000m
duty:
continuous running
insulation class:
B/F
protection class:
IP44/ IP54/IP55
cooling type:
IC0141
apply machines and equipments:
drilling machines ,blowers , pumps and so on
type:
MS series electric motor
brand:
julante and OEM
Packaging & delivery
Lead time:
Quantity(pieces) 1 - 10 >10 Lead time (days) 15 To be negotiated
Product Overview
Three Phase Motor
3 Phase Ac Induction Motor is made of high quality cast iron.With optimized construction design,they can ensure the requirement
of structure rigidity and intensity.Silicon steel plate is used in stator core and rotor core,it has good insulation on
surface,low loss which ensures the higher efficiency.High quality insulation material combines the perfect insulation system which
makes the insulation completely without clearance,high rigidity of the winding end,it can endure switching and reversing
intensity,F class insulation makes the motor with higher heat stability and longer life.
FEATURES AT A GLANCE
We use die-casting technology to ensure the stable quality of the rotor and aesthetic appearance.
The design of bearing and motor construction focuses on motor type,force on the motor,speed,lubricate type,including
bearing,design of oil sea and lubricant etc.It has the advantage of credible performance and easy maintenance.For the frame size
from 250 and below,we generally use closed bearing;frame size above 250 we use open type.Bearing.Regreasing can be done during
running.Perfect primer ensures the motors with good apperance and the motors are durable.We can also use special corrosion
protection coating.
Right elevation
Left elevation
Front elevation
PRODUCT SPECIFICATIONS
PRODUCT CONFIGURATION
Rotor
Stator
Motor Casing
Exhibition
Transport
