Yueqing Yomin Electric Co., Ltd

Overview

Essential details

• Place of Origin:

• Zhejiang, China

• Brand Name:

• Yomin

• Model Number:

• YEM021GC-N

• Display Type:

• Analog Only

• Phase:

• Three Phase

• Measuring Energy Range:

• 0-999999.9kWh

• Accuracy Class:

• 1.0

• Output Voltage:

• 3X127/220,3X230/400V

• Operating Temperature:

• -20°C~+60°C

• Dimensions:

• 123*65*100

• Display:

• 6 Digits Register

• Rated Current:

• 5(100)A

• Color:

• White

• Standard:

• IEC62053-21

• Frequency:

• 50HZ/60HZ

• Certificate:

• CE ROHS

• Type:

• Energy Digital Kwh Meter

• Communication:

• RS 485

• Product name:

• Three Phase Electronic RS485 Energy Meter

• OEM:

• Allowed

Supply Ability

• Supply Ability

• 100000 Piece/Pieces per Year

Packaging & delivery

• Packaging Details

Conventional export packing:Transparent polybag, paper box or foam box, carton or pallet.

• Port

Ningbo or Shanghai

• Lead time:

• Quantity(pieces)	1 - 1	>1
  Lead time (days)	7	To be negotiated

Din Rail Three Phase Modbus Digital Kwh Meter Smart Electric Meters With RS485

Product circuit measurement part of a dedicated measurement chip, high reliability, high precision and accurate measurement of active energy. The product adopts the linear power supply, the metering chip converts the electric energy into pulse respectively. The microprocessor completes the functions of power collection, power calculation, power pulse output and LCD display processing. The data security adopts redundant design, and the data adopts multiple backup to ensure reliable measurement data.

We can supply a wide range of products suitable for 100VAC to 380VAC (50 or 60Hz). In addition to our regular power meters, we have developed our own prepaid smart card form, prepaid smart track card form, rechargeable smart card. As well as a complete set of PC-based pre-paid management operating system. For more information, please contact us.

The meter has the following features, the meter with large-screen LCD display, the meter with RS485 (communication protocol MODBUS-RTU remote meter reading function, can accurately measure the active energy.

A  Front panel            Material                                                                  Length     100 mm

B  meter cover          Front panel flame retardant PC                                  Width      123 mm

C  bottom                  Meter cover flame retardant ABS or PC                    High        65 mm

D  seal                       Flame-retardant ABS or PC                                      Weight     0.6 Kg (net)
