Overview
Essential details
Customized:
Yes
Place of Origin:
Guangdong, China
Brand Name:
Bosslyn
Model Number:
BK-2SW
Type:
Floor Socket
Grounding:
Standard Grounding
Rated Voltage:
120 Volt
Rated Current:
15A
Application:
Residential / General-Purpose
WIFI:
NO
Name:
Dual Switch Socket
Other name:
switch socket
Flammability:
Rated V-2 per UL94
Back Cover:
Thermoplastic
Body Material:
PC
Assembly Screws:
Steel, Zinc Plated
Terminal Screws:
Brass
Standards and Certifications:
UL498
Tripping threshold:
5mA Tripping time <25ms
Working temperature:
-35 -66
Warranty:
3months-1year
Certification:
UL
Packaging & delivery
Selling Units:
Single item
Single package size:
5X5X5 cm
Single gross weight:
0.140 kg
Package Type:
Carton Size: 38*31*23.5 CM Package: 50pcs/CTN G.W: 9.2 KG
Lead time:
Quantity(pieces) 1 - 100 >100 Lead time (days) 7 To be negotiated
15A 120V Bosslyn US Standard home appliances single pole double Toggle switch
Product Description
Description of BK-02S Doblue Socket:
| Name | US double switch |
| Model | BR-2SW |
| Color | White |
| Material | PC&copper |
| Current | 15A |
| Voltage | 120V |
| Certification | UL |
Product application :
Cafes,Office,Kitchens,Bedrooms,Restaurants,Meeting Rooms,Airport lounges,Labs,Hotels,Schools,Libraries
Product fetures:
Good heat dissipation
-Design of bottom grid,good cooling
Super high impact resistance and thermal stability
-Cover pans are made of high quality polycarbonate
Chemical corrosion resistance
-Fingerprint-resistant zinc plated mounting brackets
Mechanical characteristics
Mechanical life
-Unloaded plug≥5000Sec
Meet the standard
-UL498 CSA-C22.2 NO.42 USB1.0/2.0/3.0 UL file Number:E500631
-Hounsing material flame retardant grades
Specifications,Electrical performance,Ambient temperature
-Rated working current:10A
-Rated working voltage:120V
-Power frequency:60Hz
-USB voltage and current:5VDC 4A
-Wire specifications:#14—#10AWG
-USB Compatible products:USB1.0/2.0/3.0 Includes Apple products
-Electric strength:Pressure resistance 1500V 50Hz Duration 1Min
-Working temperature:-20ºC~60ºC
-Insulation resistance:>50MΩ(DC500V)
Colour:Black Brown White lvory Almond Gray Red
Pictures
