Best price Good quality aluminum wire conductor acsr 75 mm2 50 95 120 100 from China
Product Description
Our company founded in 2008, with own factory, have more business experience.
Aluminum Alloy Conductor Steel Reinforced
1.Application
The AACSR conductors are also suitable for use in all practical transmission towers,and other structures. Application range from extra high voltage(EHV) transmission lines to sub-service spans at distribution or utilization voltages on private premises as like as ACSR.
AACSR(Aluminum Alloy Conductor Steel Reinforced) has also a long service record because of its economy ,dependability, and strength to weight ratio. The combined light weight and high conductivity of aluminum with strength of the steel cores enable higher tensions ,less sag,and longer spans than any alternative as like as ACSR.Compared with ACSR ,the tensile strength of aluminum conductor is more strong.
2.Construction:
Aluminum Alloy 6201 wires and the steel cores are concentrically stranded and wrapped helically around a central wire. The additional corrosion protection is available through the application of grease to the cores or infusion of the complete cable with grease.
3.Standard:
ASTM B711,DIN 48206,IEC61089
