Product Description
Rated working voltage (Ue) | 380V | |||
Rated insulation voltage (Ui) | 660V | |||
Auxiliary circuit insulation voltage (Ui) | 380V | |||
Rated impulse withstand voltage (Uimp) | 6kV | |||
Rated frequency (fn) | 50Hz | |||
Rated current (InA) | 400A~100A | |||
Rated short-time withstand current (Icw) | 10kA | |||
Rated peak withstand current (Icw) | 17kA | |||
Rated total capacity (Qc) | 420kvar~60kvar | |||
Enclosure rating | IP30 | |||
Compensation phase number | Combination of three-phase compensation and single compensation | |||
Indoor type (outdoor type) | Indoor type | |||
