Overview

Product Description

Manufacturer UL2725 30V 28 AWM 2725 Bare Copper Conductor Braid Shielded PVC Jacket USB Cable Electric Wire



PRODUCT DEscriptION:

Rated temperature: 60℃ or 80℃
Rated voltage: 30V
Reference Standard: UL Subject 758, UL1581
Stranded, tinned or bare copper conductor

Lead free PVC insulation
Passes UL VW-1 vertical flame test
Application: For internal or external wiring of Class 2 systems equipment and
electronic equipment



CoresStranded ConductorInsulationDrain WireOverall ShieldJacketMaximum Resistance at 20 ℃
Ω/km
AWGNo./mmDia.
mm
Nom. Thick.
mm
Nom.Dia.
mm
No./mmMaterialSpiral
No./mm
Braid
No./No./mm
Nom. Thick.
mm
Nom.Dia.
mm
2307/0.10.300.250.80--45/0.10.502.70354
22819/0.080.400.150.70---0.402.20220
4307/0.10.300.250.80--59/0.10.392.90354
4267/0.160.480.261.00-AL16/5/0.120.875.00139
8307/0.10.300.130.56-AL58/0.10.703.50354
11287/0.1270.380.220.827/0.16AL16/7/0.120.605.20223
11287/0.1270.380.140.66--16/6/0.120.383.65223
13287/0.1270.380.140.667/0.127AL16/5/0.120.534.50223
