<1>. QDY30A submersible Water Level Sensor, its 304 &316 stainless steel and hermetically sealed housing make it suitable for most industrial liquids . <2>. The welded housing is tested in-house via a helium leak tester to ensure proper protection. Ventilation tube in the cable automatically compensates for changes in atmospheric pressure above the tank. <3>. The conductors of the cable are also isolated from the outside environment to keep the level sensor operational for long-term use.

Measuring range	0-0.2-500m range can becustomized
Overload capacity	200%
Responsetime	5ms(upto90%FS)
Medium temperature	-40~60°℃
Ambienttemperature	-40~85℃
Power supply voltage	DC24VDC12Vpowersupply
Output signal	4-20mA,0-5V1-5V0-10Vthree-wire
Stable performance	±0.2%FS/year
Process connection	Submersible,intothe liquidundertest
Pressure Type	Gauge,Absolute
Storagetemperature	-40~125℃
Zero temperature drift	±2%FS
Sensitivitytemperature drift	±2%FS
Mechanicalvibration	20g(20~5000Hz)
Shock	100g(11ms)
Responsetime	<1ms(upto90%FS)
Insulation	100mΩ/250VDC
Media Compatibility	Various mediacompatiblewith316Lstainless steel
