I. Parameter

Model:   HZLY-35

Nominal flow: 2000L/h

Net oil capacity: 33L/min

Pumping rate: 25M³/h

Ultimate vacuum: ≤1000Pa

Working pressure: ≤0.5Mpa

Working oil temperature:20~80℃

Working power supply: 50Hz380V three-phase three-wire

Heating power: 24Kw (Separate control by two groups)

Total power: 27kw

Operating noise: ≤75dB(A)

Inlet/outlet flange: DN25

Vacuum interface flange: DN25

Dimensions: 150×105×150cm

Equipment weight: 340Kg

Continuous working time: ≥200 hours

Average trouble-free working time:≥ 5000 hours

Company Information

HUAZHENG Electric Manufacturing (Baoding) Co., Ltd is established in year of 2008, located at Baoding city, Hebei province, China. It is a professional company specializing in the development and production of electric power testing equipment. Main Product:  transformer oil test series, high voltage test series, cable fault location system, microcomputer relay protection test set, etc. All of our products comply with international quality standard and obtained CE and ISO 9001 certificate. Heibei Huanhai import & Export Trading Co.,Ltd is a trading company established by Huazheng Electric.

We insist on customer orientation and provide you with high quality products, reasonable prices, timely delivery and efficient service. We are willing to work with global clients for joint development and create value and success for our customers continuously.
