Model

TR4000WX

TR6000WX

TR8000WX

Rating Voltage

51.2V

51.2V

51.2V

Cell model/Configuration

3.2V100Ah/16S1P

3.2V100Ah/16S2P

3.2V280Ah/16S1P

Rating Capacity

100Ah

200Ah

280Ah

Rated Energy(kWh)

5.12kWh

10.24kWh

14.34kWh

Max.Charge/Discharge Current(A)

100A

200A

200A

Voltage Range(Vdc)

44.8V~58.4V

Scalability

Up to 15 parallel

Communication

CAN/RS485/RS232/Bluetooth /WIFI

Cycle Life

≥8000Cydes@25℃，80%DOD

Design Life

≥15Years(25°C)

display usage

LCD color touch display

MECHANICAL SPECIFICATIONS

Weight(Net/Gross)(KG)

53kg

99.5kg

132.5kg

Dimension(W/D/H)(mm)

600*500*167mm

850x650x167mm

850x650x245mm

Installation Mode

Wall Mounnted

IP Grade

IP54

SECURITY AND CERTIFICATION

Safety(Pack）

UN38.3,MSDS,IEC62619(CB),CE-EMC

Safety(Cell)

UN38.3,MSDS,IEC62619,CE,UL1973,UL2054

Protection

Smart BMS,Breake and Aerogel Fireproofing（optional）

ENVIRonMENTAL SPECIFICATIONS

Operating Temperature(°C)

Charge 0℃~65℃; Discharge -20℃~65℃

Altitude(m)

≤2000

Humidity

≤95%(Non-condensing)
