Model Output options

15V2A

15V5A

30V5A

30V10A

60V5A

100V3A

15V20A

150V2A

Output setting comment

0~rated voltage, 0~rated current, continuous adjustable, single output channel

Input voltage

Option for AC 110V±10%, 50Hz or AC 220V±10%, 50/60Hz

Voltage Stability

≤± (0.2%+5digits)

Current Stability

≤± (0.5%+5digits)

Load Stability

≤0.5%

Ripple and Noise

≤1% (Valid values)

Voltage Resolution

＜100V : 10mV; ≥100V : 100mV

Current Resolution

＜100A : 10mA; ≥100A : 100mA

Power Resolution

＜10W : 1mW ; ≥10W : 10mW; ≥100W : 0.1W ; ≥1000W : 1W

Load Equivalent Resistance Display Resolution

＜10R : 1mR ; ≥10R : 10mR; ≥100R : 0.1R ; ≥1000R : 1R

Output voltage preset accuracy

0.1V

Output current stabilization preset accuracy

0.1A

Communication Interface

Not standard, optional

Five powerful protection

Over load protection for voltage,current,power, temperature; and short circuit protection

Product size

H150×W80×D230mm

Package Size

H220×W150×D290mm

Product net weight

2KG

Packge weight

3KG
