PRODUCT SPECIFICATIONS

Product Overview

Iron powder inductors

Iron powder cores are a common magnetic core material used in inductors, power filters, transformers, and other applications. Iron powder cores are made by mixing fine iron particles with insulating material. They have the following characteristics:Characteristics1. Wide Frequency Range: Iron powder cores are typically suitable for a wide frequency range, especially in the low to mid-frequency range (tens of kHz to several MHz). They are commonly used in energy storage inductors in switching power supplies and inductor elements in power converters.2. Low Permeability: Iron powder cores have relatively low permeability, usually ranging from 10 to 100. This allows them to operate under higher currents without saturating easily, making them suitable for high-current applications.3. High Saturation Flux Density: Iron powder cores have a high saturation flux density (B_sat), which allows them to perform well in high-power applications.4. Low Loss: Although iron powder cores have higher losses compared to ferrite cores, they exhibit relatively low losses in low-frequency applications. However, as the frequency increases, the losses in iron powder cores also increase.

Color CodingIron powder cores are often color-coded to indicate different permeability, material composition, and frequency ranges. Common color codes for iron powder cores include:

Yellow/White: Represents a core with permeability of 26, commonly used in power filter inductors.Red: Represents permeability of 52, suitable for a broad range of applications.Green/Blue: Represents permeability of 125, used in high-frequency, low-power applications.Gray: Represents permeability of 75. These color codes help engineers quickly distinguish between different types of iron powder cores and select the right material for specific circuit designs and operating conditions.Applications

Power Filters: In switching power supply circuits, iron powder cores are commonly used in input filters, output filters, and energy storage inductors, providing high-efficiency energy conversion.Chokes: In EMI filtering and noise suppression applications, iron powder cores can suppress high-frequency noise due to their high saturation flux density.Transformers: Iron powder cores play an important role in energy transfer and conversion in isolation transformers or high-frequency transformers.

In summary, iron powder cores are ideal for high-power, high-frequency inductor applications due to their excellent frequency response and strong current-handling capability.
