Low Voltage switch cabinet switchboard Of 50Hz 380V 3 Phase Customizable Products Electrical distribution Switchgear

General introduce

1.LV low voltage distribution cabinet is suitable for three-phase AC 50HZ, voltage 380V/440V, rated current to 6300A power distribution system , it is widely used in power plants, substations, industrial and mining enterprises etc energy consumer and using for power, lighting and distribution equipment for electrical energy conversion, distribution and control purposes

2.Protection grade is IP40. IP20-IP43 could be optional according to the requirements of service condition.

3.Good appearance. easy assembly and disassembly.

MAIN FEATURES1.Ambient air temperature: -5℃~+40℃ and the average temperature should not exceed +35℃ in 24h
2.Indoor altitude above sea level: Maximum installation altitude: 2000m
3.Relative humidity should not exceed 50% at max temperature +40℃. Higher relative humidity is allowed at lower temperature. Ex.90% at +20℃. But in view of the temperature change, it is possible that moderate dews will produce casually.
4.No fire, explosion danger, serious pollution, chemical corrosion and severe vibration
5.Installation gradient not exceed 5°
6.The equipment shall be installed in a place where there is no violent vibration and impact, and the place where the electrical components are not corroded.
7.Any specific requirement, consult with GP service.

Cabinet size:
W800(1000)×1000×2200mm Suit for Siemens and similar breaker;
