JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor

Introduction
<1>Product uses: Used for measuring DC, AC, pulse current and other arbitrary waveform current.
<2>Product advantages: Better cost performance, low power consumption, small volume, light weight, easy installation, perforation input and no insertion loss.
<3>Product application: Frequency conversion speed control system, electric welding machine, electrochemistry, power supply monitoring, electric locomotive, low level starting protection.
<4>The input, output, power and outer shell are isolated, with strong anti-interference ability and high reliability.
<5>Full channel configuration,Parameter customizable.

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor



Technical Parameter
InstallationPlane screw fixation

Original Side

rated current

100A;200A;500A;800A;1000A;Customized

Original Side

Measuring  Range

100A~1200A

Rated Output

5V;DC0~20mA;DC4~20mA;Customized

Auxiliary Power SupplyDC12V;DC24V;DC±12V;DC±15V
Load Capacity

Voltage Output:5mA;

Current Output:6V

Temperature Drift≤500PPM/℃
Consumption Current≤25mA
Respond Time <200ms

Isolation

Pressure Resistance

2.5kV/50Hz,1Min
Quiescent Current<10mA
Action Current<40mA
Frequency BandwidthDC~20KHz
Offset Voltage≤20mvV
Zero Point Output≤0.15mA
Working Temperature-10℃~+70℃
Storage Temperature-25℃~+85

Dimension

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor

Wiring Diagram

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor

Selection

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor

Product Display

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensorJXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor

Certification

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor

Application

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor

Company&Factory

JXK-10  Close Loop Hall Effect  AC/DC Current Transducer 0-600A Input hall current sensor
