Detail

Product Description

Specification

Product model: H05v-u: 300 / 300V single copper wire conductor ≤ 1.0mm ² H05v-r: 300 / 300V, 7 copper wire conductors ≤ 1.0mm ² H05v-k: 300 / 300V multiple thin copper wire conductors ≤ 1.0mm ² H07v-u: 450 / 750V single copper wire conductor ≥ 1.5mm ² ≤6mm ² H07v-r: 450 / 750V multiple thin copper wire conductors ≥ 2.5mm ² H07v-k: 450 / 750V multiple thin copper wire conductors ≥ 1.5mm ² Application standard: DIN VDE 0281-5-2002 hd21.3s3:1995 + A1:1999 Cable structure: Conductor: oxygen free bare copper wire / tinned conductor insulation: T12 environmental protection insulation color: optional rated temperature: 70 ℃ Rated voltage: 300 / 300V, 450 / 750V

model	Specifications	Number of conductors	Conductor diameter	Approximate density (kg / km)	Near insulation outer diameter (mm)
model	Specifications	Number of conductors	Conductor diameter	Approximate density (kg / km)	Nominal outer diameter / lower limit		Outer diameter upper limit
H05V-U	0.5	1	0.8	9.7	2.0	～	2.2
H05V-U	0.75	1	0.98	12.6	2.2	～	2.4
H05V-R	0.75	7	0.37	13.0	2.3	～	2.5
H05V-U	1	1	1.13	15.3	2.3	～	2.5
H05V-R	1	7	0.43	16.1	2.5	～	2.7
H07V-U	1.5	1	1.38	21.9	2.8	～	3.0
H07V-R	1.5	7	0.52	22.5	3.0	～	3.2
H07V-U	2.5	1	1.78	34.0	3.4	～	3.6
H07V-U	4	1	2.25	49.3	3.9	～	4.1
H07V-U	6	1	2.76	69.5	4.4	～	4.6
H07V-R	10	7	1.35	117.6	6.1	～	6.3
H07V-R	16	7	1.7	174.6	7.1	～	7.4
H07V-R	25	7	2.14	276.0	8.8	～	9.1
H07V-R	35	7	2.52	367.9	10.0	～	10.5
H07V-R	50	19	1.83	525.0	11.7	～	12.2
H07V-R	70	19	2.14	686.3	13.5	～	14.0
H07V-R	95	19	2.52	964.4	15.8	～	16.3
H07V-R	120	37	2.03	1201	17.4	～	17.9
H07V-R	150	37	2.26	1478	19.4	～	19.9

H07V-R	2.5	19	0.41	35.3	3.7	～	3.9
H07V-R	4	19	0.52	51.3	4.3	～	4.5
H07V-R	6	28	0.52	70.9	4.9	～	5.1
H07V-R	10	49	0.52	121.2	6.4	～	6.6
H07V-R	16	75	0.52	175.9	7.8	～	8.0
H07V-R	25	116	0.52	269.0	9.7	～	9.9
H07V-R	35	165	0.52	369.9	11.1	～	11.5
H07V-R	50	235	0.52	523.8	13.3	～	13.7
H07V-R	70	330	0.52	716.5	15.2	～	15.7
H07V-R	95	447	0.52	992.3	16.3	～	17.1
H07V-R	120	565	0.52	1236.0	18.0	～	18.8
H07V-R	150	707	0.52	1546.5	20.1	～	20.9

H05V-K	0.5	28	0.15	9.9	2.1	～	2.3
H05V-K	0.75	24	0.2	13.6	2.3	～	2.5
H05V-K	1	32	0.2	15.9	2.5	～	2.7
H07V-K	1.5	48	0.2	22.9	3.0	～	3.2
H07V-K	2.5	51	0.25	35.3	3.7	～	3.9
H07V-K	4	56	0.3	52.0	4.3	～	4.5
H07V-K	6	84	0.3	72.3	5.2	～	5.4
H07V-K	10	80	0.4	118.5	6.6	～	6.8
H07V-K	16	127	0.4	179.2	7.9	～	8.1
H07V-K	25	199	0.4	276.7	9.8	～	10.2
H07V-K	35	278	0.4	375.1	11.1	～	11.5
H07V-K	50	396	0.4	532.2	13.3	～	13.8
H07V-K	70	558	0.4	729.9	15.3	～	16.3
H07V-K	95	756	0.4	984.8	17.7	～	18.7
H07V-K	120	956	0.4	2211.4	18.9	～	19.9
H07V-K	150	706	0.52	2760.0	20.8	～	21.8
H07V-K	185	871	0.52	3404.9	23.1	～	24.1
H07V-K	240	1130	0.52	4417.5	26.0	～	27.0
